600/1000V Mica+LSZH Insulated, Non-sheathed Power Cables to BS EN 50525-3-31 (Single Core)
FFX100 1mZ1-R(CU/MGT+LSZH 600/1000V Class 2)
General Description
FFX100 1mZ1-R fire resisting cable conforms to BS EN 50525-3-31 standard, featuring annealed copper Class
2 conductor, mica glass tape fire barrier, and LSZH (low smoke zero halogen) thermoplastic insulation. Rated
600/1000V with 70°C operating temperature, it passes IEC 60331-21, BS 6387 circuit integrity, IEC 60332
flame retardance, IEC 60754 halogen-free, and IEC 61034-2 low smoke emission tests. Designed for power
stations, mass transit underground systems, airports, petrochemical plants, hotels, hospitals, and high-rise
buildings, this single-core fire-rated cable maintains critical emergency power supply during fire incidents.
APPLICATION
600/1000V Mica+LSZH Insulated, Non-sheathed Power Cables to BS EN 50525-3-31 (Single Core) are
mainly used in power stations, mass transit underground passenger systems, airports, petrochemical plants,
hotels, hospitals and high-rise buildings.
STANDARDS
Basic design adapted from BS EN 50525-3-31
FIRE PERFORMANCE
Circuit Integrity |
IEC 60331-21; BS 6387; BS 8491 |
|---|---|
Flame Retardance (Single vertical wire or cable test) |
IEC 60332-1-2; EN 60332-1-2 |
Reduced fire Propagation (Vertically-mounted bundled wires & cables test) |
IEC 60332-3-24; EN 60332-3-24 |
Halogen free |
IEC 60754-1; EN 50267-2-1 |
No Corrosive Gas Emission |
IEC60754-2; EN 50267-2-2 |
Minimum Smoke Emission |
IEC 61034-2; EN 61034-2 |
VOLTAGE RATING
600/1000V
CABLE CONSTRUCTION
Conductor : Copper conductor according to BS EN 60228 class 2.
Fire Barrier : Mica glass tape.
Insulation : Thermoplastic compound of type TI 7 to EN 50363-7.
Insulation Option : UV resistance, hydrocarbon resistance, oil resistance, anti-rodent and anti-termite
properties can be offered as option.
COLOUR CODE
Black, Blue, Brown, Grey, Orange, Pink, Red, Turquoise, Violet, White, Green and Yellow.
PHYSICAL AND THERMAL PROPERTIES
Maximum temperature range during operation : 70°C
Maximum short circuit temperature (5 Seconds) : 160°C
Minimum bending radius :
OD<8mm : 4 × Overall Diameter
8mm≤OD≤12mm : 5 × Overall Diameter
OD>12mm : 6 × Overall Diameter
CONSTRUCTION PARAMETERS
Conductor |
FFX100 1mZ1-R |
||||
|---|---|---|---|---|---|
No. of Cores × Cross-sectional Area |
Conductor Class |
Nominal Insulation Thickness |
Min. Overall Diameter |
Max. Overall Diameter |
Approx. Weight |
No.×mm² |
|
mm |
mm |
mm |
kg/km |
1×1.5 |
2 |
0.7 |
3.7 |
4.3 |
28 |
1×2.5 |
2 |
0.8 |
4.3 |
5.0 |
42 |
1×4 |
2 |
0.8 |
4.8 |
5.6 |
59 |
1×6 |
2 |
0.8 |
5.3 |
6.2 |
81 |
1×10 |
2 |
1.0 |
6.6 |
7.7 |
133 |
1×16 |
2 |
1.0 |
7.4 |
8.8 |
197 |
1×25 |
2 |
1.2 |
9.1 |
10.7 |
308 |
1×35 |
2 |
1.2 |
10.0 |
11.9 |
412 |
1×50 |
2 |
1.4 |
11.6 |
13.8 |
558 |
1×70 |
2 |
1.4 |
13.1 |
15.6 |
782 |
1×95 |
2 |
1.6 |
15.1 |
18.1 |
1078 |
1×120 |
2 |
1.6 |
16.6 |
19.8 |
1342 |
1×150 |
2 |
1.8 |
18.3 |
21.9 |
1650 |
1×185 |
2 |
2.0 |
20.3 |
24.3 |
2067 |
1×240 |
2 |
2.2 |
23 |
27.6 |
2703 |
1×300 |
2 |
2.4 |
25.5 |
30.6 |
3378 |
1×400 |
2 |
2.6 |
28.5 |
34.2 |
4267 |
1×500 |
2 |
2.8 |
31.5 |
37.9 |
5359 |
1×630 |
2 |
2.8 |
35 |
42.1 |
6884 |
Note: The parameters listed above are nominal values as per cable standards. Actual values may vary due to material and manufacturing process variations. For precise specifications or customized requirements, please contact us for further information
ELECTRICAL PROPERTIES
Conductor operating temperature: 70°C
Ambient temperature: 30°C
Current-Carrying Capacities (Amp) according to BS 7671:2008 table 4D1A
Conductor cross-sectional area |
Ref. Method A (enclosed in conduit in thermally insulating wall etc.) |
Ref. Method B (enclosed in conduit on a wall or in trunking etc.) |
Ref. Method C (clipped direct) |
Ref. Method F (in free air or on a perforated cable tray horizontal or vertical) |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
Touching |
Spaced by one |
||||||||||
2 cables, single-phase a.c. or d.c. |
3 or 4 cables, three-phase a.c. |
2 cables, single-phase a.c. or d.c |
3 or 4 cables, three-phase a.c. |
2 cables, single-phase a.c. or d.c. flat and touching |
3 or 4 cables, three-phase a.c. flat and touching or trefoil |
2 cables, single-phase a.c. or d.c. flat |
3 cables, three-phase a.c. flat |
3 cables, three-phase a.c. trefoil |
2 cables, single-phase a.c. or d.c. or 3 cables three-phase a.c. flat |
||
Horizontal |
Vertical |
||||||||||
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
mm² |
A |
A |
A |
A |
A |
A |
A |
A |
A |
A |
A |
1.5 |
14.5 |
13.5 |
17.5 |
15.5 |
20 |
18 |
- |
- |
- |
- |
- |
2.5 |
20 |
18 |
24 |
21 |
27 |
25 |
- |
- |
- |
- |
- |
4 |
26 |
24 |
32 |
28 |
37 |
33 |
- |
- |
- |
- |
- |
6 |
34 |
31 |
41 |
36 |
47 |
43 |
- |
- |
- |
- |
- |
10 |
46 |
42 |
57 |
50 |
65 |
59 |
- |
- |
- |
- |
- |
16 |
61 |
56 |
76 |
68 |
87 |
79 |
- |
- |
- |
- |
- |
25 |
80 |
73 |
101 |
89 |
114 |
104 |
131 |
114 |
110 |
146 |
130 |
35 |
99 |
89 |
125 |
110 |
141 |
129 |
162 |
143 |
137 |
181 |
162 |
50 |
119 |
108 |
151 |
134 |
182 |
167 |
196 |
174 |
167 |
219 |
197 |
70 |
151 |
136 |
192 |
171 |
234 |
214 |
251 |
225 |
216 |
281 |
254 |
95 |
182 |
164 |
232 |
207 |
284 |
261 |
304 |
275 |
264 |
341 |
311 |
120 |
210 |
188 |
269 |
239 |
330 |
303 |
352 |
321 |
308 |
396 |
362 |
150 |
240 |
216 |
300 |
262 |
381 |
349 |
406 |
372 |
356 |
456 |
419 |
185 |
273 |
245 |
341 |
296 |
436 |
400 |
463 |
427 |
409 |
521 |
480 |
240 |
321 |
286 |
400 |
346 |
515 |
472 |
546 |
507 |
485 |
615 |
569 |
300 |
367 |
328 |
458 |
394 |
594 |
545 |
629 |
587 |
561 |
709 |
659 |
400 |
- |
- |
546 |
467 |
694 |
634 |
754 |
689 |
656 |
852 |
795 |
500 |
- |
- |
626 |
533 |
792 |
723 |
868 |
789 |
749 |
982 |
920 |
630 |
- |
- |
720 |
611 |
904 |
826 |
1005 |
905 |
855 |
1138 |
1070 |
Voltage Drop (Per Amp Per Meter) according to BS 7671:2008 table 4D1B
Conductor cross-sectional area |
2 cables d.c. |
2 cables, single-phase a.c. |
3 or 4 cables, three-phase a.c. |
|||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Ref. Methods A&B (enclosed in conduit or trunking) |
Ref. Methods C & F(clipped direct, on trays or in free air) |
Ref. Methods A & B (enclosed in conduit or trunking) |
Ref. Methods C & F (clipped direct, on trays or in free air) |
|||||||||||||||||||
Cables touching |
Cables spaced* |
Cables touching, Trefoil |
Cables touching, Flat |
Cables spaced*, Flat |
||||||||||||||||||
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
||||||||||||||
mm² |
mV/A/m |
mV/A/m |
mV/A/m |
mV/A/m |
mV/A/m |
mV/A/m |
mV/A/m |
|||||||||||||||
1.5 |
29 |
29 |
29 |
29 |
25 |
25 |
25 |
25 |
||||||||||||||
2.5 |
18 |
18 |
18 |
18 |
15 |
15 |
15 |
15 |
||||||||||||||
4 |
11 |
11 |
11 |
11 |
9.5 |
9.5 |
9,5 |
9.5 |
||||||||||||||
6 |
7.3 |
7.3 |
7.3 |
7.3 |
6.4 |
6.4 |
6.4 |
6.4 |
||||||||||||||
10 |
4.4 |
4.4 |
4.4 |
4.4 |
3.8 |
3.8 |
3.8 |
3.8 |
||||||||||||||
16 |
2.8 |
2.8 |
2.8 |
2.8 |
2.4 |
2.4 |
2.4 |
2.4 |
||||||||||||||
r |
x |
z |
r |
x |
z |
r |
x |
z |
r |
x |
z |
r |
x |
z |
r |
x |
z |
r |
x |
z |
||
25 |
1.75 |
1.80 |
0.33 |
1.80 |
1.75 |
0.20 |
1.75 |
1.75 |
0.29 |
1.80 |
1.50 |
0.29 |
1.55 |
1.50 |
0.175 |
1.50 |
1.50 |
0.25 |
1.55 |
1.50 |
0.32 |
1.55 |
35 |
1.25 |
1.30 |
0.31 |
1.30 |
1.25 |
0.195 |
1.25 |
1.25 |
0.28 |
1.30 |
1.10 |
0.27 |
1.10 |
1.10 |
0.170 |
1.10 |
1.10 |
0.24 |
1.10 |
1.10 |
0.32 |
1.15 |
50 |
0.93 |
0.95 |
0.3 |
1.0 |
0.93 |
0.19 |
0.95 |
0.93 |
0.28 |
0.97 |
0.81 |
0.26 |
0.85 |
0.8 |
0.165 |
0.82 |
0.8 |
0.24 |
0.84 |
0.8 |
0.32 |
0.86 |
70 |
0.63 |
0.65 |
0.29 |
0.72 |
0.63 |
0.185 |
0.66 |
0.63 |
0.27 |
0.69 |
0.56 |
0.25 |
0.61 |
0.55 |
0.16 |
0.57 |
0.55 |
0.24 |
0.6 |
0.55 |
0.31 |
0.63 |
95 |
0.46 |
0.49 |
0.28 |
0.56 |
0.47 |
0.18 |
0.50 |
0.47 |
0.27 |
0.54 |
0.42 |
0.24 |
0.48 |
0.41 |
0.155 |
0.43 |
0.41 |
0.23 |
0.47 |
0.4 |
0.31 |
0.51 |
120 |
0.36 |
0.39 |
0.27 |
0.47 |
0.37 |
0.175 |
0.41 |
0.37 |
0.26 |
0.45 |
0.33 |
0.23 |
0.41 |
0.32 |
0.15 |
0.36 |
0.32 |
0.23 |
0.4 |
0.32 |
0.3 |
0.44 |
150 |
0.29 |
0.31 |
0.27 |
0.41 |
0.3 |
0.175 |
0.34 |
0.29 |
0.26 |
0.39 |
0.27 |
0.23 |
0.36 |
0.26 |
0.15 |
0.3 |
0.26 |
0.23 |
0.34 |
0.26 |
0.3 |
0.40 |
185 |
0.23 |
0.25 |
0.27 |
0.37 |
0.24 |
0.17 |
0.29 |
0.24 |
0.26 |
0.35 |
0.22 |
0.23 |
0.32 |
0.21 |
0.145 |
0.26 |
0.21 |
0.22 |
0.31 |
0.21 |
0.3 |
0.36 |
240 |
0.18 |
0.195 |
0.26 |
0.33 |
0.185 |
0.165 |
0.25 |
0.185 |
0.25 |
0.31 |
0.17 |
0.23 |
0.29 |
0.16 |
0.145 |
0.22 |
0.16 |
0.22 |
0.27 |
0.16 |
0.29 |
0.34 |
300 |
0.145 |
0.16 |
0.26 |
0.31 |
0.15 |
0.165 |
0.22 |
0.15 |
0.25 |
0.29 |
0.14 |
0.23 |
0.27 |
0.13 |
0.14 |
0.19 |
0.13 |
0.22 |
0.25 |
0.13 |
0.29 |
0.32 |
400 |
0.105 |
0.13 |
0.26 |
0.29 |
0.12 |
0.16 |
0.20 |
0.115 |
0.25 |
0.27 |
0.12 |
0.22 |
0.25 |
0.105 |
0.14 |
0.175 |
0.105 |
0.21 |
0.24 |
0.1 |
0.29 |
0.31 |
500 |
0.086 |
0.11 |
0.26 |
0.28 |
0.098 |
0.155 |
0.185 |
0.093 |
0.24 |
0.26 |
0.1 |
0.22 |
0.25 |
0.086 |
0.135 |
0.16 |
0.086 |
0.21 |
0.23 |
0.081 |
0.29 |
0.30 |
630 |
0.068 |
0.094 |
0.25 |
0.27 |
0.081 |
0.155 |
0.175 |
0.076 |
0.24 |
0.25 |
0.08 |
0.22 |
0.24 |
0.072 |
0.135 |
0.15 |
0.072 |
0.21 |
0.22 |
0.066 |
0.28 |
0.29 |
Note: *Spacings larger than one cable diameter will result in a large voltage drop.
r = conductor resistance at operating temperature
x = reactance
z = impedance
