SF141C-FEP
Construction：
| Inner conductor | Silver plated steel |
Φ0.91 mm |
|---|---|---|
| Dielectric | Solid PTFE |
Φ2.98 ± 0.10 mm |
| Outer conductor | Tin Dipped Copper Braid |
Φ3.58 ± 0.10 mm |
| Shield coverage |
|
100% |
| Sheath | FEP |
Φ4.10 mm |
Electrical & Mechanical Characteristics：
| Impedance | 50±2 Ohm |
|---|---|
| Nominal capacitance | 95.1pF/m |
| Velocity of propagation | - |
| Insulation resistance | - Mohm.Km |
| Inner conductor resistance | - Ohm/Km |
| Outer conductor resistance | - Ohm/Km |
| Max.operating voltage | 1.9KV |
| Operating temperature range | -65°C - +165 °C |
| Min.bending radius | 8 mm |
Attenuation：
| Frequency(GHz) | Max. Attenuation(dB/100m) | Max. Attenuation(dB/100ft) |
|---|---|---|
0.5 |
26 |
8.0 |
1 |
39 |
12.0 |
5 |
99 |
30.0 |
10 |
152 |
46.0 |
20 |
239 |
73.0 |
